KK-256B DMX Controller 256 Channels for Club Stage DJ Lighting

Model Number:KK-256B
● 256-Channel Professional DMX512 Control supports standard DMX512/1990 protocol and controls up to 16 moving heads or 64 dimmer channels for flexible stage lighting operation.
● Automatic Fixture Library Generation simplifies fixture setup and programming, helping operators configure compatible moving heads faster without complex manual library creation.
● 35 Built-In Shape Effects include circles, spirals, rainbows, chases, and other movement patterns for quickly creating dynamic moving head scenes and stage effects.
● Flexible Shape Parameter Control allows independent adjustment of amplitude, speed, interval, wave, and direction for faster creation of customized movements and lighting scenes.
● Advanced Scene & Playback Programming stores up to 80 playback scenes with as many as 600 steps per multi-step scene and supports 16 scenes running simultaneously.
● 16 Master Faders & Fast Live Control provide button triggering, fader-based playback, preset attribute control, and instant blackout for responsive operation during live shows.
● USB Backup & Power-Failure Memory protect programmed show data through backup, restoration, same-model console sharing, and automatic data retention during unexpected outages.
● Bilingual LCD & Remote Software Upgrades combine a backlit Chinese/English interface with remote upgrade support, making operation and future feature updates more convenient.
Request a Quote
OEM&ODM
Professional production
Customer Services
24/7 support team
index banner
New Feel Lighting
256-channel-dmx-lighting-controller
watch video
256 Channel DMX512 Control
Compliant with standard DMX512/1990 protocol, the console provides up to 256 control channels for flexible stage lighting programming and operation.
Control Up to 16 Moving Heads
Supports up to 16 moving head fixtures or 64 dimmer channels, making it suitable for compact and medium-size DMX lighting systems.
2048 Channel DMX Lighting Controller
Automatic Fixture Library
Automatic fixture library generation simplifies fixture setup and helps operators get compatible lighting equipment ready for programming faster.
35 Built In Shape Effects
Includes 35 preset shapes such as circles, spirals, rainbows, and chases for quickly creating movement and dynamic lighting effects.
Stage Lighting Controller
256 Channel DMX512 Control
Compliant with standard DMX512/1990 protocol, the console provides up to 256 control channels for flexible stage lighting programming and operation.
Control Up to 16 Moving Heads
Supports up to 16 moving head fixtures or 64 dimmer channels, making it suitable for compact and medium-size DMX lighting systems.
Automatic Fixture Library
Automatic fixture library generation simplifies fixture setup and helps operators get compatible lighting equipment ready for programming faster.
35 Built In Shape Effects
Includes 35 preset shapes such as circles, spirals, rainbows, and chases for quickly creating movement and dynamic lighting effects.

Flexible Shape Programming
Shape speed, amplitude, interval, wave, and direction can be adjusted independently, giving operators more control over customized lighting scenes.
2048 Channel DMX Controller
Event Lighting
Flexible Shape Programming
Shape speed, amplitude, interval, wave, and direction can be adjusted independently, giving operators more control over customized lighting scenes.
dmx light control
Programmable DMX Controller
Advanced Scene Playback
Stores up to 80 playback scenes with as many as 600 steps per multi-step scene. Up to 16 playback scenes can run simultaneously during live operation.
16 Master Control Faders
Sixteen master faders support fast scene and fixture control, with both button triggering and fader-based operation for convenient live performance use.
DMX Lighting Console


Specifications
Download Catalogue
Model
KK-256B
Product Type
DMX Lighting Controller
DMX Standard
DMX512/1990
DMX Channels
256 channels
Scene Memory
Up to 48 scenes
Chase Programs
16 chases (programmable)
Fixtures Supported
Up to 32
Channel per Fixture
8
Display
LCD screen
Real time blackout
Support
X/Y value by wheel
Support
Chase speed by wheel
Support
Dimmer by slider
Support
Shapes for each Scene
2
Power Supply
AC 100-240V / 50-60Hz
Frequently Asked Question
Q1: What applications is this 256 Channel DMX Controller suitable for?
A:
It is suitable for DJ setups, clubs, stages, small to medium events, and moving head lighting systems. It can control up to 16 moving heads or 64 dimmer channels.
Q2: How do I know if 256 DMX channels are enough for my lighting system?
Q3: What lighting fixtures can this DMX controller work with?
A:
The controller follows the standard DMX512/1990 protocol and supports compatible moving heads, dimmers, and other DMX lighting fixtures. Automatic fixture library generation also helps simplify fixture setup.
Q4: Can I create moving head effects and programmed scenes?
A:
Yes. The console includes 35 built-in shapes such as circles, spirals, rainbows, and chases. It also stores up to 80 playback scenes with up to 600 steps per multi-step scene.
Q5: Is the controller suitable for live show operation?
A:
Yes. It provides 16 master faders, button triggering, preset attribute faders, instant blackout, and simultaneous playback of up to 16 scenes for responsive live control.
Q6: Does it support data backup and customized configurations?
A:
USB backup and restoration are supported, and show data can be shared between consoles of the same model. Chinese or English interface and panel labeling are available; other customization requirements should be confirmed before ordering.
Q7: What after-sales and delivery support is available?
A:
The console supports remote software upgrades for future feature updates, while power-failure memory helps protect programmed data. Delivery terms, lead time, and additional after-sales services should be confirmed according to order quantity and destination.
256-channel-dmx-lighting-controller
For a closer look at the system’s real-world performance—sharp beam quality, smooth animations - we invite you to explore our YouTube channel.
