DMX Controllers

GrandMA2 Full Size Stage Lighting Console

NewFeel Laser
The grandMA2 light is the perfect tool to control all kinds of lighting genres like conventionals, moving lights, LEDs, video and media.
It supplies an intuitive and fast control of all connected fixtures and channels.
The grandMA2 light can handle an almost infinite number of presets, cues, pages, sequences and effects. It is ideally suited as a standalone console or as a backup device for the grandMA2 full-size.
Moreover grandMA series 1-showfiles can be converted to be used with the grandMA2.
Request a Quote
OEM&ODM
Professional production
Customer Services
24/7 support team
index banner
New Feel Lighting
THIS IS A VIDEO OF Our Story
watch viedo
DMX Outputs
7DMX outputs, the maximum expansion can support 65536 channels of built-in parameters.
Touch Screen
315.4-inch touch screen, 19-inch touch screen can be connected with two touch display.
GrandMA2 Stage Light Console
Electric Push Rod
30 high-precision electric putters 60mm, 2AB fields Electric push rod (100mm), 1 master electric push rod.
Hardware
7 wear-resistant encoders (with Push function), 1 high-sensitivity trackball, 1 high-precision dimming well, 2 Gigabit Ethernet ports, 4 USB 2.0 ports, adjustable display clamshell.
GrandMA2 Stage Light Console
DMX Outputs
7 DMX outputs, the maximum expansion can support 65536 channels of built-in parameters.
Touch Screen
315.4-inch touch screen, 19-inch touch screen can be connected with two touch display.
Electric Push Rod
30 high-precision electric putters 60mm, 2AB fields Electric push rod (100mm), 1 master electric push rod.
Hardware
7 wear-resistant encoders (with Push function), 1 high-sensitivity trackball, 1 high-precision dimming well, 2 Gigabit Ethernet ports, 4 USB 2.0 ports, adjustable display clamshell.
Built-in Drawer and Built-in Keyboard.
Independent orange backlit keys, MIDI input and output interface LTC/SMPTE time code, support for extended pushrods, 2 LED gooseneck light sockets, 1SSD, Inteli3 CPU, 4GB RAM, 2 Geforce graphic cards.
GrandMA2 Stage Light Console
GrandMA2 Stage Light Console
Built-in Drawer and Built-in Keyboard
Independent orange backlit keys, MIDI input and output interface LTC/SMPTE time code, support for extended pushrods, 2 LED gooseneck light sockets, 1SSD, Inteli3 CPU, 4GB RAM, 2 Geforce graphic cards.
GrandMA2 Stage Light Console
GrandMA2 Stage Light Console
Software
Supports both. Chinese and English languages, Linux operating system, support for DMX512, Artnet, ACN protocol, the system can be installed via disk, program data can be saved on hard disk or U disk Support multiple inline back-ups, supports handheld remote control, Supports 3D effect simulation on the stage, real-time on-site simulation, the system can be installed via U disk Program data can be saved on hard disk or U disk, supports DMX512, Artnet, ACN protocol, supports RDM management, supports Wysiwyg connection, massive lamp library supports LTP and HTP.
Summary
Size: 94cm * 65cm * 21cm 1: Imported industrial screen, higher brightness, wider viewing angle, fully silent backlit professional mechanical keys (adjustable backlight brightness) 2: Built-in push-pull professional backlit mechanical keyboard (adjustable backlight brightness) 7 industrial-grade encoders imported from Germany (with Push function) 3: Electric display screen back panel adjustment (0-80 degree adjustable angle) wide voltage design: AC 165V--260V, power: 450W4: Built-in UPS power supply, with under-voltage and over-voltage protection functions. Solid and reliable solid-state hard disk to ensure data security and faster storage. Two work light sockets (the console integrates work light switch function)
GrandMA2 Stage Light Console
Specifications
Download Catalogue
DMX outputs
6 DMX outputs, 1 DMX input, connection extender, up to 65536 channels
Built-in 3 electric adjustable
wide viewing angle 15.4 inch touch screens and a 1 9-inch high-brightness multi-touch screen
Electric faders
30 high-precision electric faders (60mm) and 2 AB field electric faders (100mm)
Optical encoders
1 master electric putter, 7 German optical encoders (with PUSH function)
Sensitive Trackball
A highly sensitive trackball
Signals
2 Gigabit Ethernet ports, support MA NET, ARTNET, ETC NET2, PATHPORT,SCAN, SHOWNET, KINET1 signals,5 USB 2.0 ports.
Backlit Buttons
Adjustable yellow backlit buttons, built-in keyboard and drawer.
Output Interface
MIDI input and output interface
Built-in solid-state hard drive
Compatible with MA1 and MA2 systems
