12x60W RGBW Pixel Zoom LED Moving Head Light Bar IP65
Model Number：NF-Q1000
● 12×60W RGBW Pixel Zoom Output delivers powerful beam and wash effects with RGBW 4-in-1 LEDs for professional stage lighting and outdoor events.
● Individual Pixel Control System allows each LED to be controlled independently, creating dynamic patterns, chasing effects, and creative lighting visuals.
● Beam, Wash & Strobe Effects combines narrow beam projection, wide wash coverage, and high-output white strobe effects in one LED moving head light bar.
● 4.5°–36° Motorized Zoom System provides flexible beam adjustment from focused effects to wider lighting coverage for different stage designs.
● IP65 Outdoor LED Light Bar Design ensures reliable performance in rain, dust, and harsh environments for outdoor lighting applications.
● DMX512, RDM & Multiple Control Modes supports DMX512, RDM, auto-run, master-slave, and sound control for professional lighting systems.
● RGBW & CMY Color Mixing Effects delivers rich color combinations and smooth transitions for concerts, festivals, clubs, and event lighting.
Request a Quote
New Feel Lighting
18x10W RGBW Pixel Bar
watch video
12×60W RGBW Pixel Zoom Light Bar Performance
Equipped with 12pcs × 60W RGBW 4-in-1 LEDs, this LED moving head
light bar delivers powerful beam and wash effects with high brightness for stage lighting, concerts, and outdoor events.
Individual Pixel Control & Dynamic Strobe Effects
Each LED can be controlled independently to create dynamic pixel effects, chasing patterns, and creative lighting visuals.
The additional white LED strobe system provides powerful flash effects with adjustable speed.
Motorized Zoom Beam & Wash System
The 4.5°–36° motorized zoom range allows flexible transitions from narrow beam effects to wide wash coverage.
RGBW and CMY color mixing options provide versatile stage lighting possibilities.
IP65 Waterproof Outdoor Design
Built with IP65 protection, this RGBW LED light bar is designed for outdoor lighting applications.
It operates reliably in temperatures from -40°C to 45°C for demanding environments.
High-Output Strobe & Creative Lighting Effects
The built-in white strobe system delivers up to 14,700lm output with adjustable 1–25Hz strobe effects.
Multiple effect modes create dynamic visuals for concerts, festivals, and events.
Outdoor Stage & Event Lighting Applications
Designed for concerts, festivals, clubs, rental productions, and architectural lighting projects.
The durable IP65 housing and powerful RGBW output make it suitable for professional outdoor installations.
Specifications
Download Catalogue
Light Source
12 × 60W RGBW 4-in-1 LEDs + 120 × 1W White Strobe LEDs
Power
800W
Voltage
AC 200–240V, 50/60Hz
Effects
Beam / Wash / Pixel / Strobe Effects
Pixel Control
Individual LED Control
Zoom
4.5°–36° Motorized Zoom
Strobe
1–30Hz High-Speed Strobe
Color Mixing
RGBW + CMY Mixing Effects
Brightness:
Main Output: 8,380 lm
Strobe Output
Up to 14,700 lm
Dimming
0–100% Linear Dimming
Strobe
1–25Hz Adjustable
Control
DMX512 / RDM / Auto / Master-Slave / Sound
Protection
IP65 Waterproof
Operating Temperature
-40°C to 45°C
Housing
Magnesium Alloy
Size
1000 × 232 × 321 mm
Weight
30.5 kg
Frequently Asked Question
Q1: What makes this 12×60W RGBW light bar different from standard LED bar lights?
Q2: What effects can this RGBW moving head light bar create?
Q3: How does the zoom function improve lighting performance?
Q4: Is this IP65 LED moving head light bar suitable for outdoor use?
Q5: Does it support DMX512 and RDM control?
Q6: Where can this pixel zoom bar moving head light be used?
Q7: Do you provide OEM service and technical support?
12x60W RGBW Pixel Zoom LED Moving Head Light
For a closer look at the system’s real-world performance—sharp beam quality, smooth animations - we invite you to explore our YouTube channel.
